125 x 60 (65) mm Bottom Multico Combi Rebate & Limiter Head

Code 120A00130
1 In Stock
£224.00each
(£268.80 including VAT)
£224.00each
Was £0.00
(£268.80 including VAT)
Decrease
Increase
Specifications
  • Height60 mm
  • Diameter125 mm
  • Suitable for MDFYes
  • Max RPM7500 rpm
  • Number of Cutters2
  • Number of Spurs2
  • Shear or Straight?Shear
  • Product MaterialALUMINIUM
  • Top or Bottom?Bottom
  • MAN or MECMAN
  • Product Weight2.2 kg
  • Min RPM4000 rpm
  • Bore Diameter1 1/4 inches
View Terms & Glossary
Rebate/limiter profile combi head for two headed Multico Tenoner. Rebating section for square tenons and profile section for profile scribe. To take 65 mm G blanks and 60 mm TC reversible rebate blades. Designed with recess to flush mount both heads on 20 mm shafts. Supplied with TC rebating section (inc. spurs), profile scribes sold separately. Body in light aluminium.
